1 x Clear CMOS Switch
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
Storage
•
10 x SATA3 6.0 Gb/s Connectors, support RAID (RAID
0, RAID 1, RAID 5, RAID 10 and Intel Rapid Storage 13),
NCQ, AHCI and Hot Plug
(S_SATA3_2 is shared with the SATA DOM; S_SATA3_3 is
shared with the eSATA)
* RAID is supported on SATA3_0 ~ SATA3_5 ports only.
•
2 x SATA3 6.0 Gb/s Connectors by Marvell SE9172, support
RAID (RAID 0 and RAID 1), NCQ, AHCI and Hot Plug
* Marvell SE9172 RAID is supported with Windows® OS only.
•
1 x SATA DOM Connector (shared with S_SATA3_2)
•
1 x SATA Express 10 Gb/s Connector (shared with SATA3_4
and SATA3_5)
* Support to be announced
•
1 x eSATA Connector, support NCQ, AHCI and Hot Plug
•
1 x M.2_SSD (NGFF) Socket 3, supports M.2 SATA3 6.0
Gb/s module and M.2 PCI Express module up to Gen2 x 4 (20
Gb/s)
* If M2_1 is occupied by a SATA-type M.2 device, S_SATA3_0
will be disabled.
* If you install a M.2 PCI Express module and the SATA_EXP0
is in use, the M2_1 will downgrade to x2 mode.
Connector
•
1 x COM Port Header
•
1 x Chassis Intrusion Header
•
1 x TPM Header
•
1 x Power LED Header
•
2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
•
3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin) (Smart Fan
Speed Control)
•
1 x Power Fan Connector (3-pin)
•
1 x SB Fan Connector (3-pin)
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
•
1 x SATA DOM Power Header
•
2 x PCIe Power Connectors
