Page #65 background imageLoading...
Page #65 background image
58 59
English
Z270M-IT X/ac
PCH PCIE ASPM Support
is option enables/disables the ASPM support for all PCH PCIE devices.
DMI ASPM Support
is option enables/disables the control of ASPM on CPU side of the DMI Link.
PCH DMI ASPM Support
is option enables/disables the ASPM support for all PCH DMI devices.
IOAPIC 24-119 Entries
Enables/Disables IOAPIC 24-119 Entries. IRQ24-119 may be used by PCH devices.
Disabling those interrupts may cause certain devices failure.
Share Memory
Congure the size of memory that is allocated to the integrated graphics processor when
the system boots up.
IGPU Multi-Monitor
Select disable to disable the integrated graphics when an external graphics card is installed.
Select enable to keep the integrated graphics enabled at all times.
Onboard LAN
Enable or disable the onboard network interface controller.
Onboard HD Audio
Enable/disable onboard HD audio. Set to Auto to enable onboard HD audio and
automatically disable it when a sound card is installed.
Front Panel
Enable/disable front panel HD audio.
Onboard HDMI HD Audio
Enable audio for the onboard digital outputs.
Riser Card Support
Enable/disable the support of riser card.
WAN Radio
Enable/disable the WiFi module's connectivity.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK Z270M-ITX/AC and is the answer not in the manual?

ASROCK Z270M-ITX/AC Specifications

General IconGeneral
Audio chipRealtek ALC892
Cooling typePassive
CertificationFCC, CE, WHQL, ErP/EuP
Component forPC
Power source typeATX
Motherboard chipsetIntel® Z270
PC health monitoringCPU, FAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factormini ITX
Motherboard chipset familyIntel
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory32 GB
Supported memory clock speeds2133, 2400, 2800, 2933, 3200, 3600, 3733 MHz
Processor socketLGA 1151 (Socket H4)
Compatible processor seriesIntel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 seriesi3-6xxx, i5-6xxx, i7-6xxx
Maximum number of SMP processors1
DirectX version12.0
Maximum resolution4096 x 2160 pixels
Number of SATA III connectors6
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
BIOS typeUEFI AMI
ACPI version6.0
BIOS memory size128 Mbit
USB connector typeUSB Type-A
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controllerIntel I211, Intel I219V
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version4.0
Ethernet interface typeGigabit Ethernet
RAID levels0, 1, 5, 10
Cables includedSATA
Bundled softwareASRock A-Tuning ASRock Disk Health Report ASRock USB Key ASRock APP Charger ASRock XFast LAN ASRock XFast RAM ASRock Fast Boot (Fast Boot, Restart to UEFI) ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash ASRock Internet Flash ASRock Crashless BIOS ASRock UEFI System Browser ASRock UEFI Tech Service ASRock Easy RAID Installer ASRock Easy Driver Installer
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width170 mm
