Z270M-IT X/ac
Congure between module write to write delay.
tWRWR_dg
Congure between module write to write delay.
tWRWR_dr
Congure between module write to write delay.
tWRWR_dd
Congure between module write to write delay.
Fourth Timing
MRC Fast Boot
Enable Memory Fast Boot to skip DRAM memory training for booting faster.
Voltage Conguration
CPU Vcore Voltage
Congure the voltage for the CPU Vcore.
CPU Load-Line Calibration
CPU Load-Line Calibration helps prevent CPU voltage droop when the system is
under heavy load.
CPU Core AC Loadline
AC Loadline dened in 1/100 mOhms. A value of 100 = 1.00 mOhm. and 1255 =
12.55 mOhm. Range is 0-6249 (0-62.49 mOhms). 0 = AUTO/HW default. Uses
BIOS mailbox command 0x2.
GT Voltage
Congure the voltage for the integrated GPU.
GT Load-Line Calibration
GT Load-Line Calibration helps prevent GT voltage droop when the system is under
heavy load.
DRAM Voltage
Use this to congure DRAM Voltage. e default value is [Auto].
PCH +1.0 Voltage
Congure the chipset voltage (1.0V).
