Associated Electrics RC10 B6.4D TEAM KIT - Page 20

20
:: :: Bag 10 - Step 2Bag 10 - Step 2
:: :: Bag 10 - Step 3Bag 10 - Step 3
31531
M3 x 6mm
BHCS
89218
3 x 8mm
Washer
x2x2
x2x2
x2x2
91731
Battery
Strap, B6
91731
B6 Battery
Strap Nut
Make sure the
battery strap
shoulder screw is
flush with the top of
your battery pack!
!
RRFF
91731
Battery
Strap, B6
91730
Battery Strap
Shoulder
Screw
x2x2
ESC not
included!
6727
Servo
Tape
Antenna can be mounted
on the right or left side of
the chassis.
!
Receiver not
included!
Transponder
not included!
25225
M3 x 3mm
Set Screw
6338
Antenna
Tube & Cap
91158
M3 x 4mm
BHCS
x2x2
