:: :: Bag 2 -Bag 2 - Step 6Step 6
:: :: Bag 2 Bag 2 -- Step 5Step 5
:: :: Bag 2 Bag 2 -- Step 4Step 4
31531
M3 x 6mm
BHCS
91885
Servo Mount
Brace
91887
Servo
Mount
x2x2
x2x2
#1596
thread lock
#91728 - Servo Spacers
are not required for most servos.
!
41089
M3 x 6mm
LP SHCS
x4x4
#1596
thread lock
25202
M3 x 10mm
FHCS
x2x2
#1596
thread lock
91971
Top Plate,
B6.4
25187
M3 x 14mm
BHCS
x2x2
The front hinge pin
brace has a sharp
edged side, and a
rounded edge side.
Mount the sharp
edge side towards
the bulkhead.
!
25211
M3 x 10mm
BHCS
x2x2
31510
M2 x 4mm
BHCS
91673
Front Arms,
Gull Wing, B6
91657
Front Hinge
Pin Brace,
B6
x2x2
