:: :: Bag 3 - Step 1Bag 3 - Step 1
:: :: Bag 2 - Step 8Bag 2 - Step 8
8
:: :: Bag 2 -Bag 2 - Step 7Step 7
!
#91978 - Front Wing Mount is used as a tuning option to
increase front end stabillity by adding a front wing (included).
If you do not use #919778, use #25202
M3x10mm FHCS instead of #89208 M3x14mm FHCS.
25215
M3 Locknut,
black
71144
Steering
Block Arm,
+1mm
91047
Heavy-duty
Ballstud,
6mm
91670
Front Hinge Pin
(Inner, 3x34mm)
25225
M3 x 3mm
Set Screw
x2x2
x2x2
25204
M3 x 16mm
FHCS
91685
Front
Bumper
x2x2
!
25188
M3 x 20mm
BHCS
91815
Shock
Bushing,
10mm
91880
Front Shock
Tower, B6.3,
Gull-Wing
91885
Front Shock
Tower Cover
91885
Front Shock
Tower Nut
x2x2
x2x2
31520
M2.5 x 6mm
BHCS
x2x2
33
22
11
25202
M3 x 10mm
FHCS
89208
M3 x 14mm
FHCS
91978
Wing Mount,
Front
x2x2x2x2
Build 2 (1 left, 1 right)
x2x2
31531
M3 x 6mm
BHCS
91560
5 x 10 x 4
Bearing
91682
Front Axle
91901
Steering
Block
(4mm)
#1596
thread lock
There are two sets of steering
blocks included with your kit, a 3mm
and a 4mm. The 4mm steering
blocks are used for the kit setup.
!
Bearing
There are two sets of steering
blocks included with your kit, a 3mm
4L - 1
