Associated Electrics RC10 B7 TEAM KIT - Page 18

18
:: :: Bag 9 -Bag 9 - Step 7 Step 7
:: :: Bag 9 -Bag 9 - Step 8 Step 8
!
!
Build x2 (right and left side)
x2x2
25612
M3 Locknut
w/Flange
Make sure the fl ange on
the shock pivot ball is
towards the rear arm.
25612
M3 Locknut w/
Flange
Build x2 (right and left side)
Use outside
hole in
front arm!
25189
M3 x 22mm
BHCS
33
44
22
BC
A
11
33
22
BC A
11
