1................... Cover
2................... Introduction
3...................1:1 Hardware “Fold Out”
4................... Table of Contents
5....................Steering Build
Bag 1
5....................Front Suspension Build
Bag 2
8....................Caster / Steering Blocks Build
Bag 3
9....................Rear Suspension Build
Bag 4
10.................Gear Differential Build
Bag 5
11..................Gearbox Build
Bag 6
14.................Rear Hubs Build
Bag 7
15.................Turnbuckles Build
Bag 8
16..................Shocks Build
Bag 9
19.................Electronics Build
Bag 10
22..................Tuning Tips
24................ Setup Sheet “Kit Setup”
25................ Setup Sheet “Blank”
26................ Back Cover
!
There is a 1:1 hardware foldout page in the front of the manual.
To check the size of a part, line up your hardware with the correct
drawing until you fi nd the exact size. Each part in the foldout has
a number assigned to it for ordering replacement parts.
This symbol indicates a special
note or instruction in the manual.
This symbol indicates the order
within a step to assemble parts.
This symbol indicates there
are optional FT parts available
This symbol indicates
where Black Grease
should be applied.
This symbol indicates
where FT Diff Lube
should be applied.
*not included
This symbol indicates
where FT Silicone Grease
should be applied.
*not included
This symbol indicates
where Thread Lock
Adhesive should be
applied. *not included
This symbol indicates
where Shock Fluid
should be applied.
This symbol indicates
where Diff Fluid
should be applied.
This symbol indicates
where Green Slime can
be applied.
*not included
This symbol indicates the number
of the same part that is required.
BLACK GREASE
#6588
FT DIFF LUBE
#6591
FT SILICONE
GREASE #6636
FT GREEN SLIME
#1105
THREAD
LOCK
#1596
SHOCK
FLUID
DIFF
FLUID
2
x2x2
This symbol indicates a Racers Tip.
