Associated Electrics RC10 B74.2 TEAM KIT - Page 5

:: :: Bag 1Bag 1 - - Step Step 2 2
:: :: Bag 11 - - Step 3 3
5
:: :: Bag 1 -Bag 1 - Step 1 Step 1
6/22
x7x725201
3x8mm
FHCS
x4x4
x2x2
25201
M3x8mm
FHCS
4670
M3x8mm
SHSS
25202
M3x10mm
FHCS
92315
B74.2
Chassis
25215
M3
Locknut
x2x292112
Side Guards,
(left & right)
92113
Chassis
Brace,
Front
92113
Chassis
Brace,
Rear
Shorter battery O-ring strap
to be used with low-profi le
batteries. Longer battery
O-ring strap to be used with
standard height batteries.
92268 LP battery posts
included. These will not
be used in the kit and
can be discarded
Multiple thickness
spacers included to
tune battery position
which affects the weight
bias of the car.
Kit Setup uses the
thickest spacer behind
the battery, no spacer
in front of the battery.
Position 4.
!
!
!
x8x831532
M3x8mm
BHCS
25211
M3x10mm
BHCS
92268
ESC
Tray
92268
Fan
Mount
92255
Chassis brace
support, front
(G10 2mm)
92316
Battery
spacers
92255
Chassis brace
support, rear
(G10 2mm)
Fan
(Not included)
x2x2
x2x2
x2x2
31541
M3x6mm
FHCS
25202
M3x10mm
FHCS
31541
M3x6mm
FHCS
89203
M3x16mm
BHCS
92316
Battery
o-ring hook,
rear
92316
Battery
mount, rear
Shorter battery O-ring strap
to be used with low-profi le
!
x2x231519
M2.5x5mm
BHCS
92316
Battery
mount, front
92316
Battery
o-ring hook,
front
92316
Battery
o-ring
