:: Introduction:: Introduction
Thank you for purchasing this Team Associated product. This assembly manual contains instructions and tips for building
and maintaining your new vehicle. Please take a moment to read through the manual and familiarize yourself with the steps.
We are continually changing and improving our designs; therefore, actual parts may appear slightly different than the
illustrations. New parts will be noted on supplementary sheets located in the appropriate parts bags.
Check each bag for these sheets before you start to build.
Check www.AssociatedElectrics.com for the latest versions of our instruction manuals
Associated Electrics, Inc.
21062 Bake Parkway.
Lake Forest, CA 92630
http://www.AssociatedElectrics.com • • http://www.instagram.com/teamassociatedrc/ • http://www.facebook.com/TeamAssociated/
Customer Service
Tel: 949.544.7500
Fax: 949.544.7501
:: RC10B7D Team Kit Features:: RC10B7D Team Kit Features
:: Additional:: Additional
:: Other Helpful Items:: Other Helpful Items
• 5-gear laydown transmission with low profile motor mount moves weight of motor closer to the center of the car
• Long-arm suspension geometry improves grip and predictability in all conditions
• KPI adjustable steering and caster blocks allows for fine tuning steering feel. Three options are included in kit.
• Vertical front outer ballstud allows fine tuning of roll center, camber gain, and link length
• Height adjustable aluminum front bulkhead allows for further tuning of front roll center
• Standard and HRC (High Roll Center) rear hubs included
• Highly adjustable battery holder with thumb tabs allows for easy battery removal and fine tuning of weight bias
• 7075-T6 aluminum chassis with increased departure angle and optional weight plate pockets
• HD 69mm CVA bones and differential outdrives for improved durability
• Light-weight molded servo mount
• One-piece rear wing mount improves durability
• New 7-inch rear wing and 2.5-inch front wing
• Low-profile body included
• Shock tower covers front and rear
• 3.5mm turnbuckles and ballcups
• 2 cell LiPo battery pack
• Polycarbonate specific spray paint
• Cyanoacrylate glue (“CA”) (#1597)
• Thread locking compound (#1596)
• Tires and Inserts, Fronts and Rears
• Wheels w/12mm Hex
Front Wheels #9690 (white), #9691 (yelllow)
Rear Wheels #9695 (white), #9696 (yelllow)
• Slim Front Wheels w/12mm Hex (carpet/astro turf)
#91757 (white) #91758 (yelllow)
Your new RC10B7D Team Kit comes unassembled and requires the
following items for completion (refer to www.AssociatedElectrics.com
and www.Reedypower.com for suggestions):
• R/C two channel surface frequency radio system
• AA-size batteries for transmitter
• Electronic Speed Control (“ESC”)
• Steering servo
• R/C electric motor (540 size)
• Pinion gear (48P), size determined by type/turn or kV of motor
• Battery charger (a peak detection charger, or LiPo compatible charger)
• Silicone Shock Fluid (Refer to AssociatedElectrics.com for complete listings) • Green Slime shock lube (#1105)
• FT Turnbuckle Wrench, 4mm (#1112) • FT Body Reamer (#1499) • Shock Pliers (#1681) • Wire Cutters
• FT Hex/Nut Wrenches (#1519) • FT Ballcup Wrench (#1579) • Hobby Knife • Needle Nose Pliers
• FT Universal Tire Balancer (#1498) • Calipers or a Precision Ruler • FT Body Scissors (#1737) • Soldering Iron
