:: :: Bag 10 -Bag 10 - Step 3 Step 3
:: :: Bag 10 -Bag 10 - Step 4 Step 4
Battery
not included!
x2x2
92418
Battery Holder,
Standard
x4x4
x2x2
25211
M3 x 10mm
BHCS
25215
M3 Locknut
!
Standard and Low Profi le battery thumb screws
are included. Shims may need to be added if
battery weights are used.
Use M3 x 18mm for standard height
Use M3 x 12mm LP height
x2x2
x2x2
92463
Battery Holder
O-Ring
92418
Thumb Screw
!
Install hook and loop tape
(#91743) along the side braces
in 2 spots.
One near the front, and one in
the middle.
Install the opposite side of the
hook and loop tape inside the
body!
1 2 3 4 51 2 3 4 5
Kit Setting - #1Kit Setting - #1
1 2 3 4 51 2 3 4 5
StandardStandard
OffsetOffset
FrontFront
FrontFront
1/21/2
OFFSETOFFSET
!
See note at bottom
of page!
92422
B7
Body, clear
92423
B7 Body, Clear
(Light Weight)
!
There are two options for trimming the kit
body on the left rear side.
Dotted line is preff ered if you run a motor fan.
