Associated Electrics RC8B4.1e Team Kit - Steering Blocks and Front Shock Mounting - Steps 3-5; Pillow Ball Shims and Front Bumper; Front Shock Attachment

15
:: :: Steering Blocks Steering Blocks BuildBuild - Bag 6.1 - Bag 6.1 -- Step 4Step 4
:: :: Steering Blocks Steering Blocks BuildBuild - Bag 6.1 - Bag 6.1 -- Step 5
:: :: Steering Blocks Steering Blocks BuildBuild - Bag 6.1 - Bag 6.1 -- Step 3Step 3
Kit Setup:
Mount the front shock in the
outside hole on the front arm.
A B
#1596
thread lock
Pillow Ball Shims
0.35mm 0.7mm
1.4mm
81056
Suspension
Arm
Endcap
x2x2
81072
Pillow
Ball Shim
(1.4mm)
81072
Pillow
Ball Shim
(0.7mm)
25620
M3x10mm
SHCS
x2x2
89217
M4x14mm
FHCS
81264
M4x20mm
FHCS
81643
B4.1
Front
Bumper
x2x2
x2x2
#1596
thread lock
81262
M4x10mm
FHCS
31532
M3x8mm
BHCS
89216
M4
Locknut
x2x2
x2x2
89214
M4x12mm
FHCS
For attaching
steering link to
steering rack
!
Kit Setup:
1 1
2 2
3 3
25612
M3 Locknut
W/ Flange
81509
Shock
Pin
81257
M3x6mm
Set Screw
