Associated Electrics RC8B4.1e Team Kit - Battery Tray Setup - 2 s and 4 s Shorty Packs; 2 s Shorty Battery Pack Setup; 4 s Shorty Battery Pack Setup

23
:: :: Battery TrayBattery Tray Build Build - - Bag Bag 12.112.1 - Step 1- Step 1
:: :: Battery TrayBattery Tray Build Build - - Bag Bag 12.112.1 - Step 2- Step 2
25201
3x8mm
FHCS
81584
Hook and
Loop Strap
81574
Battery
Tray
81574
Battery
Tray Spacer
x4x4
x2x2
Tray
81262
4x10mm
FHCS
x4x4
Use 2s
shorty
battery
only
Reverse
ESC in
program
box
!
!
4s Shorty Pack
Configuration
Configuration
6727
Servo
Tape
81572
ESC Tray
(ESC not
included)
81262
4x10mm
FHCS
x4x4
89216
M4
Locknut
89216
M4
Locknut
x4x4
x2x2
Battery
Tray Spacer
program
box
6727
Servo
Tape
81572
ESC Tray
81262
4x10mm
FHCS
x2x2
(not included)
Use 4s
shorty
battery
only
!
!!!ALERT!!!
ESC Setup needs motor rotation = REV
Reverse Motor Rotation only
!
