Associated Electrics Reflex 14T - Page 13

13
:: :: Step 24Step 24
:: :: Step 23Step 23
:: :: Step 22Step 22
x2x2
Build x2 (right and left side)
Build x2 (right and left side)
Build x2 (right and left side)
Orient the  ange
to the left throughout the
car. It indicates which end
has the left hand threads!
!
Orient the  ange
to the left throughout the
car. It indicates which end
has the left hand threads!
!
Orient the  ange
to the left throughout the
car. It indicates which end
has the left hand threads!
!
21513
M3x35mm
turnbuckle
21513
M3x35mm
turnbuckle
21513
M3x35mm
turnbuckle
21514
Ball Cup
19.50mm
Steering Turnbuckle
20.00mm
Front Camber Turnbuckle
23.25mm
Rear Camber Turnbuckle
!
!
x2x2
21514
Ball Cup
x2x2
21514
Ball Cup
