Associated Electrics Reflex 14T - Page 3

3
:: Hardware - 1:1 Scale View:: Hardware - 1:1 Scale View
3x2.5mm (31500)
3x3mm (25225)
3x8mm (4670)
Set Screws
Notes:
M2.5 Locknut (89215, 21546)
M4 Locknuts:
Serrated Steel (Silver)(91826)
Flanged (Black) (91148)
FT Aluminum (Blue) (31551)
Serrated Aluminum (Black) (91738)
Nuts (lock/plain)
Flat Head (fhcs)
2.5x10mm (31350)
2.5x6mm (31520)
Button Head (bhcs)
2.6x6mm (21546)
2.6x8mm (21546)
2.6x10mm (21546)
Button Head (bhst)
Ball Bearings
4x7x2.5mm (21512)
4x8x3mm (21512)
8x12x3.5mm (21512)
2.7x6.7x0.5mm (21546)
4x8x0.5mm (21516)
Shims and Washers
Flat Head (fhst)
2x8mm (21546)
2.6x8mm (21546)
2.6x10mm (21546)
Cap Head (shcs)
2.5x12mm (8691)
