3
12-14..........Front / Rear Diff Access
15-...............Shock Maintenance
16.................Motor Manual
17................. ESC Manual
18-27..........Catalog
28................1:1 Hardware “Fold Out”
29................Catalog cont.
30................Trouble Shooting
:: Table of Contents
:: Notes
This symbols indicates a
special note or instruction
in the manual.
!
There is a 1:1 hardware foldout page in the back
of the manual. To check the size of a part, line
up your hardare with the correct drawing until
you find the exact size. Each part in the foldout
has a number assigned to it for ordering
replacement parts.
1....................Cover
2....................Introduction
3....................Table of Contents
4....................Blueprint of the RIVAL MT
5-7................Quick Start Guide
8....................Electronics Wiring /
Camber & Toe Settings
9...................Gear Mesh & Ride Height
10.................Spur Gear Access
11..................Center Diff Access
Associated Electrics, Inc.
26021 Commercentre Dr.
Lake Forest, CA 92630
