Associated Electrics Rival MT10 - Step 40 Assembly

19
:: Step 40
:: Step 41
Carefully apply ca glue
(tire adhesive) to the tire
bead on the side. Do one
side at a time, allowing it
to dry before gluing the
other side!
CA glue not included!
!
#1597
ca glue
Install 4
Battery
ESC
Build 4
x4
x2
6332
Body Clip
91738
M4 Black
Nut Serrated
Aluminum
25841
MT10 Insert
25841
MT10 Tire
x2
25841
Method
Race Wheel
Cap
25839
Rival MT10
Body, Painted
(Red/Blue)
25841
Method
Race Wheel
6727
Servo Tape
