:: Caster Blocks and Hubs Build - Bag 7 - Step 8
:: Caster Blocks and Hubs Build - Bag 7 - Step 9
:: Bumper, Anti-Roll Bar, and Electronics Build - Bag 8 - Step 1
Build left
and right
sides
Build left
and right
sides
31112
1/16” x 5/16”
dowel pins
31670
Clamping
wheel hex
(5mm)
91611
M1.6x5mm
shcs
Do not
overtighten!
!
Build left
and right
sides
31383
Ballstud
washer,
aluminum
(2mm)
31382
Ballstud
washer,
aluminum
(1mm)
31532
M3x8mm
bhcs
31532
M3x8mm
bhcs
x2 x2
x2
x2
31677
TC7 hinge
pin, outer
25225
M3x3
set screw
!
Orient the notch
to the left throughout
the car. The notch
indicates which end has
the left hand threads!
