Associated TC7.2 - Turnbuckle Build - Bag 4 - Step 1; Suspension Arms Build - Bag 5; Suspension Arms Build - Bag 5 - Step 1; Suspension Arms Build - Bag 5 - Step 2

9
Servo Turnbuckle
Steering Turnbuckle
Camber Turnbuckle
10.15mm
6258
3x21mm
turnbuckle
6264
3x35mm
turnbuckle
91723
3x48mm
turnbuckle
19.00mm
30.15mm
x2
20.50mm
x2 x2
31305
Turnbuckle
eyelet
Front Rear
:: Turnbuckle Build - Bag 4 - Step 1
:: Suspension Arms Build - Bag 5 - Step 1
:: Suspension Arms Build - Bag 5 - Step 2
Build two front
inner arm
mounts
31802
TC7.2 Inner
arm mount
31620
TC6.2 arm
mount insert
(Front: -3 dot)
Arm Mount Inserts
Negative to the inside of vehicle.
Positive to the outside of vehicle.
1 DOT
0 °
-2 DOT
-0.6 °
+2 DOT
+0.6 °
-1.2 °
-3 DOT
+3 DOT
+1.2 °
Build two rear
inner arm
mounts
31802
TC7.2 Inner
arm mount
31620
TC6.2 arm
mount insert
(Rear: 0 dot)
x4
x4
31541
M3x6mm
fhcs
31771
TC7.2
chassis
31384
Bulkhead
washers
(0.5mm)
x4
31541
M3x6mm
fhcs
Rear of
chassis
!
Front of
chassis
!
x4
31384
Bulkhead
washers
(0.5mm)
Arm Mount Inserts
Negative to the inside of vehicle.
Positive to the outside of vehicle.
1 DOT
0 °
-2 DOT
-0.6 °
+2 DOT
+0.6 °
-1.2 °
-3 DOT
+3 DOT
+1.2 °
