AST AD511 User Manual

9
Figures | Applied Satellite Technology
Figure 3. AD510-40 Power Break-In Box for use with +18 to +36 v DC supply.
The case is hard anodised aluminium and has fixing flanges. A 40m coil of
RG213U cable is shown connected to an AD511 active antenna (top). The
handset interconnect is shown trailing from the TNC to the bottom left, whilst
the flying lead for connection to 18 to 36 v DC supply is shown cutting the
frame to the left.

AST AD511 Specifications

General

Brand	AST
Model	AD511
Category	Antenna
Language	English
