AST PCH GMP-025 Series User Manual

QtyPart # Description
1 23836-01B 1
MANIFOLD, DISPENSE, DUAL COMPONENT, INTERNAL CHECK, .10 PORTS
2 13108 2
SPRING, COMPRESSION, .300 DIA x 7/8 L X 0.032 C/S, GMP
3 12013 2
BALL, 3/8 DIAMETER, CHROME STEEL
4 23837-01 2
SEAT, INTERNAL CHECK DISPENSE MANIFOLD, UHMW, GMP 025
5 12681 2
O-RING, 1-906, EP
6 26233 2
UNION, MANIFOLD SEAT, 9/16-18 SAE X 1/4 F NPT
7 13212 2
ZERK, GREASE, BUNA SEAL, STRAIGHT, 1/8 NPT
8 11923 2
BOLT, 1/4-20 x 1-3/4, SHCS
9 13606 2
WASHER, 1/4, LOCK, SPLIT
10 11032 2
NIPPLE, 1/4” NPT, HEX
11 11127 2
VALVE, BALL, 1/4 NPT, LP
12 11288 2
ADAPTER, 1/4 M NPT x 6 M JIC
MANIFOLD ASS’Y, 7/8-9, INTERNAL BALL, .100 PORTS, NO. 6 W/ BALL VALVE
PRODUCT NAME:
ENGINEER
55696-01C
PRODUCT #
ORIG DATE
12
# OF ITEMS
Item
