ASTEC 40 Series User Manual

IB-2003
S
eries 40 Trans
fl
ite -
S
tationary
C
onveyor
18
Introduction to the Series 40 Conveyor
Options
The following options are
available on Series 40
conveyors.
Stationary Conveyors
• Walkway
• Safety stop switch
• Vertical or horizontal gravity
take-up
• Discharge hood with rock
shelf
• Wind hoops
• Backstop
• Belt plow
• Zero speed
Transfl ite Conveyors
• Dual tires
• Skid support
• Dolly assembly
A 5’6” long material receiving
trough is used at the loading
point. This trough keeps
the conveyor evenly loaded
to maximize capacity and
reduce belt wear. The trough
is equipped with clamped
rubber fl ashing to help keep
the load centered on the belt
and reduce spillage.
Receiving Trough
