Page #10 background image
0000138174 rev.1.1 8
9 BASIC MODBUS-RTU REGISTER MAP
The table shown in this chapter is our exclusive and original register map with the name, function and address of all
registers.
Name
Holding Registers
Input
Registers
Description
ID_Address (*only read)
0x00
Slave Address (Default: 0x01)
COM_Setup (*only read)
COM CONFIGURATION
High Byte
(will be always filled, even if is the same
configuration indicated in the Low Byte)
bits 9…8 Stop bit
High Byte
bits 9…8 Stop bit
01: 1
bits 11…10 Parity bit
01: None
10: Even
11: Odd
bits 15…12 Bauds
000: 2400
001: 4800
010: 9600
Low byte
bits 2…0 standard settings
000: 9600, 8, E, 1 (default)
001: 19200, 8, E, 1
010: 9600, 8, N, 2
011: 19200, 8, N, 2
100: 9600, 8, N, 1
101: 19200, 8, N, 1
11111111: OTHER (See High Byte)
ID_Manufacturer_hi (*only read)
0x02
0x3B8B
ID_Manufacturer_lo (*only read)
0x03
0xA51F
ID_Product_code_hi (*only
read)
0x04
0x008
ID_Product_code_lo (*only
read)
0x05
0x131E
ID_Verify
0x06
ID_Verif =
ID_manufacturer_M
SB XOR
ID_manufacturer_LS
B
XOR
ID_product_code_M
SB XOR
ID_product_code_LS
B XOR 0xF00A
HW_Version (*only read)
0x07
ALWAYS KEPT TO ZERO
SW_Version (*only read)
0x08
210
Watchdog_time
0x10
Time in seconds(default 0 = disabled)
Watchdog_config
0x11
0x00 - HW Reset
0x01 - RS485 Communication Reset
0x02 - Stops All Dosages and Issue an
alarm (ala)
0x03 - Issue an alarm (alarm relay)
