Astralpool CONTROL BASIC PLUS User Manual

0000138174 rev.1.1 9
Status (*only read)
0x00
low byte
.bit 0
Alarm flag (one or more alarms are presents)
.bit 1
Function Mode
0 = pH
1 = ORP
.bit 2
Not used
.bit 3
Control Mode Status:
0/1 = System Stopped/Running
.bit 4
Not used
.bit 5
Not used
.bit 6
Not used
.bit 7
Not used
hi byte
.bit 8
0 : Normal Operation Mode
.bit 9
1 : Calibration mode
2: Programming mode
3: Logging Mode
.bit 10
RFU (Reserved Future Use)
.bit 11
RFU (Reserved Future Use)
.bit 12
Not used
.bit 13
Not used
.bit 14
Not used
.bit 15
Not used
Alarms (*only read)
0x01
See Note 2
low byte
.bit 0
Reserved
.bit 1
pH OFA
.bit 2
ORP OFA
.bit 3
Level
.bit 4
Flow
.bit 5
RFU (Reserved Future Use)
.bit 6
RFU (Reserved Future Use)
.bit 7
RFU (Reserved Future Use)
hi byte
.bit 8
RFU (Reserved Future Use)
.bit 9
RFU (Reserved Future Use)
.bit 10
RFU (Reserved Future Use)
.bit 11
RFU (Reserved Future Use)
.bit 12
RFU (Reserved Future Use)
.bit 13
RFU (Reserved Future Use)
.bit 14
RFU (Reserved Future Use)
.bit 15
Communication Watchdog
Alarm (Latch)
0x20
See Note 2
.bit 0
low byte
Reserved
.bit 1
pH OFA
.bit 2
ORP OFA
.bit 3
Level
.bit 4
Flow
.bit 5
RFU (Reserved Future Use)
.bit 6
RFU (Reserved Future Use)
.bit 7
RFU (Reserved Future Use)
.bit 8
hi byte
RFU (Reserved Future Use)
.bit 9
RFU (Reserved Future Use)
.bit 10
RFU (Reserved Future Use)
.bit 11
RFU (Reserved Future Use)
.bit 12
RFU (Reserved Future Use)
