Page #12 background imageLoading...
Page #12 background image
0000138174 rev.1.1 10
.bit 13
RFU (Reserved Future Use)
.bit 14
RFU (Reserved Future Use)
.bit 15
Communication Watchdog
In/Out states (*only read)
0x02
low byte
.bit 0
Level
.bit 1
Relay 1
.bit 2
Relay 2
.bit 3
Flow
.bit 4
Motor
.bit 5
not used
.bit 6
not used
.bit 7
not used
hi byte
.bit 8
not used
.bit 9
not used
.bit 10
not used
.bit 11
not used
.bit 12
not used
.bit 13
not used
.bit 14
not used
.bit 15
not used
Control Word (*only read)
0x21
.bit 0..2
not used
.bit 3
Control Mode 0/1 = Stop/Run System
.bit 4..15
not used
SetPoint pH
0x23
0 to 1400 (1400 = 14,00 pH)
SetPoint ORP
0x24
0 to 1000 mV
Temperature Measure
0x08
0 to 100 (100 = 100°C)
pH Measure
0x0A
0 to 1400 (1400 = 14,00 pH)
ORP Measure
0x0F
0 to 1000 mV
Start Counter
0x30
0 to 65535
Com WDT Counter
0x31
0 to 65535
Relay 1 Activations
0x32
0 to 65535
Relay 2 Activations
0x33
0 to 65535
Alarms Latch 1.bit 0 counter
0x38
0 to 65535
Alarms Latch 1.bit 1 counter
0x39
0 to 65535
Alarms Latch 1.bit 2 counter
0x3A
0 to 65535
Alarms Latch 1.bit 3 counter
0x3B
0 to 65535
Alarms Latch 1.bit 4 counter
0x3C
0 to 65535
10 PRODUCT REVISION
Manual v1.1: All the information of this manual describes the behaviour of Software Version V2.2
