ENGLISH
IMPORTANT: The instruction manual you are holding includes essential information on the safety measures to be im-
plemented for installation and start-up. Therefore, the installer as well as the user must read the instructions before
beginning installation and start-up.
Keep this manual for future reference.
To achieve optimum performance of the LumiPlus Projector, follow the instructions provided below:
1. ELECTRICAL CONNECTION
The projectors are supplied with a 2-wire 1.5mm
2
Cu H07RNF cable.
You should make sure that the voltage received by the projector is never more than 12V~AC, by a safety transformer. The
transformer must be sized to provide the VA for each projector that is connected. See power table, last page.
2. CONTROL SYSTEMS OF THE LED PROJECTORS: by means of the LumiPlus Series
The LumiPlus projector can be controlled in two differents ways: either by a normally closed pushbutton or by mens of the
modulator and/or remote control. See figures on page 14.
2.1. LumiPlus ECO: NC (normally closed) pushbutton control
The pushbutton of control must support the power of all the projectors that we connect to it. In the case of the pushbutton
with code 32458 it must be connected in the primary one of the transformer and holds a maximum power of 700VA.
The pushbutton control enables you to create different lighting scenarios inside the pool with two function modes:
Fixed colour: Selection of a fixed colour from seven possibilities
COLOUR Nº COLOUR
1 White
2 Red
3 Blue
4 Green
5 Magenta
6 Cyan
7 Yellow
Automatic colour sequence: Selection from among seven programmes of colour sequences. Each programme is defined by
the duration of each colour and of the transition from one colour to another, according to the following table:
SEQUENCE ORDER OF COLOURS
1
Red Blue Green
Magenta
Cyan Yellow
2
Red Green Cyan Blue
Magenta
Yellow
3 Magenta
Cyan Yellow - - -
4
Red Blue Green - - -
5 Magenta
Cyan Yellow - - -
6
Yellow
Magenta
Cyan - - -
7
Green Red Blue - - -
Each press of the pushbutton changes a colour or sequence. The cycle of colours and sequences is rotary. For example, if
you are in colour 6, by pressing once you will go to colour 7. If you press once again, you will go to sequence 1. If you are
in sequence 7, press once and you will go to colour 2 which is Red.
Colour 1 is white and is reached by one long press.
2.2. LumiPlus TOP: control by means of Modulator
The modulator (code 27818) must support the power of all the projectors that we connect to it, the maximum power that
it supports is 900 VA.
The Remote Control – Modulator – Transformer – LumiPlus Projector unit enables you to create different lighting scenarios
inside the pool with two function modes:
