5
The pushbutton control enables you to create different lighting scenarios inside the pool with two function modes:
6.1.2. Function modes
Fixed colour: Selection of a fixed colour from seven possibilities.
COLOUR Nº COLOUR
1 White
2 Red
3 Blue
4 Green
5 Purple
6 Cyan
7 Yellow
Automatic colour sequence: Selection from among seven programmes of colour sequences. Each programme is defined by
the duration of each colour and of the transition from one colour to another, according to the following table:
SEQUENCE ORDER OF COLOURS
1 Red
Blue Green Purple Cyan Yellow
2 Red
Green Cyan Blue Purple Yellow
3 Purple Cyan Yellow - - -
4 Red Blue Green - - -
5 Purple Cyan Yellow - - -
6 Yellow Purple Cyan - - -
7 Green Red Blue - - -
Each press of the pushbutton changes a colour or sequence. The cycle of colours and sequences is rotary. For example, if
you are in colour 6, by pressing once you will go to colour 7. If you press once again, you will go to sequence 1. If you are
in sequence 7, press once and you will go to colour 2 which is Red.
Colour 1 is white and is reached by one long press.
6.2. Control by means of the Colorplus Series
The MICRO spotlight can be used together with spotlights of the 27 LED Colorplus series, whatever its configuration may be
(TOP-ECO).
6.2.1. Colorplus ECO: pushbutton control
The same functions as the power supply control. For further information see section 6.1.2.
6.2.2. Colorplus TOP: control by means of Modulator
The Remote Control – Modulator – Transformer – Led Projector unit enables you to create different lighting scenarios inside
the pool with two function modes:
Fixed colour: Selection of a fixed colour from twelve possibilities.
1 Red 7 Sky-blue
2 Green 8 Pale Violet
3 Blue 9 Orange
4 Yellow 10 Magenta
5 Cyan 11 Emerald green
6 Purple 12 White
