Astralpool PRO-ELYO INVERBOOST 48707M - Parameter Checking and Adjustment

- 58 -
Parameter checking:
Press first, then press to check the User parameter from d0 to d11
Code
Condition
Scope
Remark
d0
IPM mould temperature
0-120℃
Real testing value
d1
Inlet water temp.
-9℃～99℃
Real testing value
d2
Outlet water temp.
-9℃～99℃
Real testing value
d3
Ambient temp.
-30℃～70℃
Real testing value
d4
Return gas temp.
-30℃～70℃
Real testing value
d5
Piping temp.
-30℃～70℃
Real testing value
d6
Gas exhaust temperature
0℃～C5℃ (125℃)
Real testing value
d7
Step of EEV
0～99
N*5
d8
Compressor running frequency
0～99Hz
Real testing value
d9
Compressor current
0～30A
Real testing value
d10
Current fan speed
0-1200 （rpm）
Real testing value
d11
Error code for last time
All error code
Press first, then press to check/adjust the User parameter from P1 to P7
Code
Name
Scope
Default
Remark
P1
Working mode
0-1
1
1 Heating mode
，
0 cooling mode
P2
Timer on/off
0-1
0
1 Timer on/off is under function
，
0 Timer on/off is
out of function (The setting of P4 and P5 won’t
work)
P3
Water pump
0-1
0
1 Always running ， 0 Depends on the running of
compressor
P4
Current time
HH:MM
00：00
0-23:0-59
P5
Timer on
HH:MM
00：00
0-23:0-59
P6
Timer off
HH:MM
00：00
0-23:0-59
P7
Inlet water
temp.
correction
-9～9
0
Default setting: 0
