Installation Guide - Igloo Plus - Size L
Page 09Proudly manufactured by ARSAT® in the European Union
Join the base rails on the left side and on the right side of the door rail. Place the stop plate on the left side of the door rail and fix it with
Join the other rails and fix them as shown in the detail C.
B
B
M8 nut
M8 nut
Door Rail
M8 nut
912 screw
912 screw
IGP07
SM850912
SM850912
NM8934
NM8934
NM8934
SM850912
IGP07
To Next Page
