Astro Pneumatic Tool 4538 - Parts Identification; Component List

ECONOMY AIR
UNDERCOAT GUN
4538
110
Index Part No. Description Qty
Index Part No. Description Qty
4538-01
4538-03
4538-04
4538-05
4538-06
4538-07
4538-08
4538-09
1
3
4
5
6
7
8
9
1
1
1
1
1
1
1
1
4538-10
4538-11
4538-12
4538-13
4538-14
4538-15
4538-16
10
11
12
13
14
15
16
1
1
1
1
1
1
1
Gun Body
Air Nozzle
Locking Nut
Material Nozzle
Suction Tube
Air Inlet Connector
Opening Stopper
Trigger
Trigger Pin
O-Ring (2.5 x 1.8)
Sealing Gasket
Air Valve Stem
Air Valve Spring
O-Ring (6.0 x 1.8)
Air Valve Seat
Call 1.800.221.9705 for questions concerning performance of the product
or other inquiries.
Page 2
