Astro Pneumatic Tool 498K - Parts Breakdown and List; Parts List

PARTS BREAKDOWN
Parts List
101
Call 1.800.221.9705 for questions concerning performance of the product
or other inquiries.
Product Type:Model:
498K
0.498" SHANK THOR AIR
HAMMER/RIVETER
Page 4
Qty
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
498K-01
498K-02
498K-03
498K-04
498K-05
498K-06
498K-07
498K-08
498K-09
498K-10
498K-11
498K-12
498K-13
498K-14
498K-15
498K-16
498K-17
498K-18
498K-19
498K-20
498K-21
498K-22
498K-23
498K-24
Handle
Cylinder THOR
Piston THOR
Bush
Valve Box
Valve
Pin
Valve Seat
Throttle Bush
Inlet Bushing
Valve Stem
O-Ring (5.7 X1.7)
Spring
Hex
Pin (4X19)
Spring Pin (3X18)
Assistant Lever
Lever
Stopper Pin
Retainer Spring
Copper Sheathing
Exhaust Conver
O-Ring (37 X 3)
Snap Ring (S38)
Index Part No. Description
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
