FIXED
WHEELS
UNIVERSAL WHEELS
W/ BRAKES
Product Type:Model:
55670
7-IN-1 WORKBENCH
Page 5
ASSEMBLY
1
2
HANDLE
BUTTONS
1. Find the wheels, gaskets and screws in the back of the
workbench, then line up all the screws, gasket and wheels.
Notice that the 2 universal wheels with brakes should be
installed under the tool tray and the left 2 fixed wheels on
the other side.
2. Put one gasket on the screw hole and secure the screw by
using a screwdriver.
3. Rotate the wheel to fix the 4 screws, make sure the wheels
are fully secured.
4. Follow steps 1-3 to assemble the other 3 wheels, then your
car creeper is ready to go.
5. Connect a pulling rope to the towing holes, then the dolly is
completed.
1. Always use the gaskets which are provided in the carton. See the illustrations above.
2. There are 2 universal/steering wheels plus 2 fixed wheels in the set, and each set of wheels has their own
position. Please refer to the illustration above.
1. Pull the handle up from the car creeper mode
until you can’t move it any more, then a hand
truck is ready.
2. Push the two buttons on the handle, it can be
withdrawed.
CAR CREEPER & DOLLY MODE
HAND TRUCK MODE
Please follow these steps to install wheels in the car creeper & dolly mode:
Please follow these steps to install wheels in the car creeper & dolly mode:
TIP : How to install the wheels
