3
Technical Specifications
Capacity 16000mAh
Net weight 316g / 11.1oz
Size 126 × 77 × 24mm / 4.9 × 3.0 × 0.9in
Input Micro USB DC 5V / 1.5A
Charging Port Output 1 USB DC 5V / 1A (min 40mAh)
Charging Port Output 2 USB DC 5V / 2A (min 80mAh)
Total Output 5V / 3A
How to Charge Your Astro E5
1. Always press the power button to check the power level before charging as
the LED lights will not automatically light when the device is fully charged.
2. Plug the Micro USB cable into the Astro E5’s input port.
3. Insert the remaining end of the USB cable into (a) an AC adapter (not
included) connected to the wall socket or (b) a charging computer USB port.
4. Push the power button to begin charging.
5. The LED indicators will remain lit when the Astro E5 is fully charged.
