2.3. Physical Characteristics
The physical characteristics of the two Max-Viz 1500 LRUs are listed below.
Characteristic
Specification
Sensor
Sensor Unit Diameter:
Depth:
Overall length:
Weight:
2.770 inch Diameter (70,3 mm)
6.179 in. (156,9 mm)
6.828 in. (173,4 mm)
< 2.5 lbs (1,13 kg)
Power Supply
Height:
Width (Enclosure):
Width (Overall):
Depth (Enclosure):
Weight:
2.250 in. (57,1 mm)
3.750 in. (95,2 mm)
5.330 in. (135,4 mm)
5.00 in. (127,0 mm)
< 2.65 lbs (1,20 kg)
2.4. Export Control
Export of the Max-Viz 1500 Sensor is governed by the Commerce Department, Bureau
of Industry and Security. The Sensor has Export Control Classification Number (ECCN)
of 6A003.b.4.b.
Max-Viz 1500 commodities, technology, or software shall be exported from the United
States in accordance with the Export Administration Regulations. Diversion contrary to
U.S. law is prohibited.
3. INSTALLATION PLANNING
All installations in certified aircraft should be performed per FAA-approved installation
instructions, such as an STC or service bulletin. This information is provided to assist in
the design of a certified installation. It is also provided to assist in non-certified aircraft
installations.
The Max-Viz 1500 is limited to a max altitude of 55,000 feet and a operating
temperature of -55C to +70C.
The +28 Vdc supply to the Power Supply should be routed through a suitably labeled
circuit breaker. Particular attention must be taken in routing the RS-170 video coax
cable through the aircraft structure to avoid potential RFI from noise items and to
minimize the cable bend radii.
