3.1. Interface Connections
3.1.1. Interconnect Pin-outs between Sensor LRU and Power Supply LRU
The cable harness between the Sensor and the Power Supply can be fabricated from
standard 22 AWG aircraft wire (e.g., M27500 twisted shielded pair). A typical
installation length is 14 to 24 inches depending on the actual locations of the two LRUs.
Notes:
 Maximum recommended LRU separation is 100 feet.
 If the harness between the Sensor and Power Supply is longer than 12 feet, a
larger AWG size is recommended (video coax excluded).
 Pin numbers are the same at each connector between the Sensor and Power
Supply.
 An overall metal cable shield tied to both ends into the connector backshells is
recommended.
 TP = Twisted Pair.
 If additional bulkhead connectors are connected in-line, each contact must be
rated for 5 Amps or more.
 Under no circumstance may signals from multiple pins be spliced and carried in a
single wire.
Sensor
Connector
Pin No.
Description
Recommended Wire
Power Supply
Connector Pin No.
1
+ 28 VDC Heater
22 AWG Shielded TP1
1
2
28 VDC RTN Heater
22 AWG Shielded TP1
2
3
+ 28 VDC Heater
22 AWG Shielded TP2
3
4
28 VDC RTN Heater
22 AWG Shielded TP2
4
5
28 VDC RTN Switched
22 AWG Shielded TP3
5
6
28 VDC RTN Switched
22 AWG Shielded TP3
6
7
+ 15 VDC
22 AWG Shielded TP4
7
8
15 VDC RTN
22 AWG Shielded TP4
8
9
+ 15 VDC
22 AWG Shielded TP5
9
10
15 VDC RTN
22 AWG Shielded TP5
10
11
RTD +
22 AWG Shielded TP6
11
12
RTD --
22 AWG Shielded TP6
12
13
RS 232 +
22 AWG Shielded TP7
13
14
RS 232 RTN
22 AWG Shielded TP7
14
15
RS 232 --
22 AWG Shielded TP8
15
16
RS 232 RTN
22 AWG Shielded TP8
16
17
17
18
Chassis/Shields
22 AWG
18
19
19
