Astronics Trig-Tek 203M - Displacement Output and DC Output

Publication No. 980978 Rev. A 203M User Manual
Astronics Test Systems Introduction 1-5
Displacement Output
Level 0-10 Volts RMS.
Impedance Less than 50 Ohms (20 mA max)
Sensitivity 10 mV/mil DA.
Amplitude Accuracy ±5% of reading ±0.5% FS.
Frequency Response
±3% 10 Hz to 10000 Hz of a –12dB slope.
±5% for 5 Hz to 3000 Hz of a –12dB slope
in series with the selected Low Pass Filter.
Dynamic Range 36dB below full scale.
DC Offset
Less than 5 millivolts (noise signal must be
averaged).
DC Output
Level 10 Volts DC full scale (meter range).
Impedance Less than 50 Ohms (10 mA max)
Sensitivity 10 Volts for selected full scale.
Linearity 1% full scale.
Amplitude Accuracy 2% of reading ±1% FS.
Dynamic Range (Accel) 60 dB below full scale.
