ASUNA 8730G - Parts List

NO.
DESCRIPTION
SPEC.
QTY
NO.
DESCRIPTION
SPEC.
QTY
1
Main Frame
1
24
Meter Upper Cover
1
2L/R
L/R Upright
2
25
Meter Under Cover
1
3L/R
Foam Handrail
2
26
Safety Key
1
4
Meter Bracket
Horizontal Tube
1
27
Safety Key Seat
1
5
Motor Seat
1
28
PC Board Light
Bracket
1
6
Nut
Φ30*23.7H
2
29
Inner Upright
Decorative Cover
2
7
Pad Bracket Single-
Sided Adhesive Tape
1
30
Outer Upright
Decorative Cover
2
8
Cable Press Sheet
5
31
Upper Motor Cover
1
9L/R
Pad Connecting Seat
2
32
Motor Bottom Cover
1
10
Meter Ring
2
33
L/R
Rear Foot Cover
2
11L/R
Side Fixing Hook
2
34
L/R
Rear End Cap
2
12
L/R
Aluminum Alloy Side
Rail
22*75*1442L
2
35
L/R
Side Foot Cover
2
13
L/R
Side Rail Insert
Sheet
7.4*79.7 *1288L
2
36
Silicon Oil
1
14
Side Rail
73.9*16.7*1218
L
2
37
Sleeve
2
15
Motor Adjusting
Screw
Φ12*M8 *34.5L
2
38
Tool
1
16
Pad Bracket
1
39
Rear Foot Cover Pad
2
17
Supporting Wheel
Axis
4
40
Bracket Front
Supporting Pad
2
18
Pad Bracket Fixing
Screw Right
1
41
Cushion
4
19
Pad Bracket Fixing
Screw Left
1
42
Rubber Spacing
Cushion
2
20
M4 Nut Clip Plate
2
43
Running Board Shock
Absorber
2
21
Running Board
1
44
Transportation Wheel
4
22
Running Belt
1
45
Font Roller
1
23
Belt
1
46
Rear Roller
1
Parts List
