Asus A68HM Series User Manual

vii
A68HM Series specifications summary
Expansion slots
1 x PCIe 3.0*/2.0 x16 slot
1 x PCIe 2.0 x1 slot
1 x PCI slot
* PCIe 3.0 is supported by FM2+ processors only.
LAN
Realtek
®
8111GR Gigabit LAN controller
Audio
Realtek
®
ALC887-VD 7.1-channel High Denition Audio CODEC
- LED-lit audio shielding*: Ensures precision analog/digital separation and
greatly reduced multi-lateral interference, with a gorgeous illuminated trace
path
- Special layout design - Separate layers for left and right channels to guard
the quality of the sensitive audio signal
- Premium Japanese-made audio capacitors: Provide warm, natural and
immersive sound with exceptional clarity and delity.
* LED-lit is supported by A68HM-E only.
• UseachassiswithHDaudiomoduleinthefrontpaneltosupporta7.1-channel
audio output.
USB
AMD
®
A68H FCH:
- 2 x USB 3.0 ports (2 ports at back panel, blue)
- 6 x USB2.0 ports (2 ports at back panel; 4 ports at mid-board)
ASUS unique
features
ASUS 5X Protection*
- ASUS DIGI+ VRM - 3+2 Phase digital power design
- ASUS Enhanced DRAM Overcurrent Protection - Short circuit damage
prevention
- ASUS ESD Guards - Enhanced ESD protection
- ASUS High Quality 5K-Hour Solid Capacitors - 2.5x long lifespan with
excellent durability
- ASUS Stainless Steel Back I/O - 3x more durable corrosion-resistant
coating
* ASUS 5X Protection Only for A68HM-E
ASUS Exclusive Features
- ASUS EPU
- ASUS USB 3.0 Boost
- ASUS AI Suite 3
- ASUS AI Charger
- ASUS Anti-Surge
ASUS Quiet Thermal Solutions
- ASUS Fanless Design: Stylish heatsink solution
- ASUS Fan Xpert
ASUS EZ DIY
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
(continued on the next page)
E9808_A68HM Series_Manual.indb 7 2014/10/16 10:08:57

Asus A68HM Series Specifications

General

Form Factor	Micro ATX
Chipset	AMD A68H
Socket	FM2+
Memory Type	DDR3
Memory Slots	2
USB Ports	8 x USB 2.0
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek RTL8111H Gigabit LAN Controller
Video Outputs	D-Sub, DVI-D, HDMI
PCIe Slots	1 x PCIe 2.0 x1
