Asus A68HM Series User Manual

vi
(continued on the next page)
A68HM Series specifications summary
CPU AMD
®
FM2+ Socket for AMD
®
A-Series/Athlon™ Series processors
AMD
®
Turbo Core Technology 3.0 support
Supports APU up to 4 cores
• Refertowww.asus.com for the AMD
®
CPU support list.
Chipset
AMD
®
A68H FCH
Memory
2 x DIMMs, max. 32GB, DDR3 2400(O.C.)/ 2133/ 1866/ 1600/ 1333 MHz,
non-ECC un-buffered memory
Dual-channel memory architecture
Supports AMD Memory Prole (AMP) memory
• HyperDIMMsupportissubjecttothephysicalcharacteristicsofindividual
CPUs.
• Themaximum32GBmemorycapacitycanbesupportedwith16GBorabove
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
• Refertowww.asus.com for the latest Memory QVL (Qualified Vendors List).
• Whenyouinstallatotalmemoryof4GBcapacityormore,Windows
®
32-bit
operating system may only recognize less than 3GB. We recommend a
maximum of 3GB system memory if you are using a Windows
®
32-bit operating
system.
Graphics
Integrated AMD
®
Radeon™ R/HD8000/7000 Series Graphics in the
A-Series APU
Multi-VGA output support: DVI-D and D-Sub
Supports Dual-link DVI with max. resolution 2560x1600@60Hz
Supports D-Sub with max. resolution 1920x1600@60Hz
AMD
®
Dual Graphics technology support*
Maximum shared memory of 2G
Supports AMD
®
Dual Graphics technology
• Refertohttp://www.amd.com/us/products/technologies/dual-graphics/
Pages/dual-graphics.aspx#3 for the discrete GPUs which support Dual Graphics
technology.
Storage / RAID
AMD
®
A68H FCH:
- 4 x Serial ATA 6.0Gb/s connectors (Grey) support RAID 0, RAID 1, RAID
10, and JBOD congurations
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS A68HM-E / A68HM-K motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories 1 x I/O Shield
Application DVD Support DVD
Documentation User Guide
• A68HM series motherboard include A68HM-E and A68HM-K. The layout illustrations
in this user manual are for A68HM-E only.
• If any of the above items is damaged or missing, contact your retailer.
E9808_A68HM Series_Manual.indb 6 2014/10/16 10:08:57

Asus A68HM Series Specifications

General

Form Factor	Micro ATX
Chipset	AMD A68H
Socket	FM2+
Memory Type	DDR3
Memory Slots	2
USB Ports	8 x USB 2.0
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
LAN	Realtek RTL8111H Gigabit LAN Controller
Video Outputs	D-Sub, DVI-D, HDMI
PCIe Slots	1 x PCIe 2.0 x1
