xi
ASMB4-iKVM/ASMB4-SOL PLUS
specications summary
Chipset
Aspeed 2050
Internal RAM
56 Mb for system
8 Mb for video
Internal ROM
16 Mb
Timers
32-bit W
atchdog T
imer
Main features
IPMI 2.0-compliant and supports
KVM over LAN
Web-based user interface (remote management)
Virtual media
Form factor
22 mm x 17 mm
* Specications are subject to change without notice.
10
12
Table of Contents
Default Chapter
3
Table of Contents
3
Notices
6
Safety Information
8
About this Guide
9
ASMB4-Ikvm/Asmb4-SOL PLUS Specifications Summary
11
Chapter 1: Product Introduction
13
Welcome
14
Package Contents
14
Features
15
System Requirements
16
Network Setup
17
Chapter 2: Installation
19
Before You Proceed
20
Hardware Installation
20
Firmware Update and IP Configuration
22
Firmware Update
22
Configure BMC IP Source Static IP
24
Configure BMC IP Source DHCP
25
BIOS Configuration
26
Running the ASMC4 Utility
29
Configuring the LAN Controller
31
Configuring the User Name and Password
32
Software Installation
33
Installing the ARC
33
Launching ARC
34
Chapter 3: ASUS Remote Console
35
ASUS Remote Console (ARC)
36
ARC Sections
37
Menu Bar
37
Tool Bar
37
Navigation Window
37
Detail/Sel Window
39
Event Window
39
Status Bar
39
Connecting to the Remote Server
40
Retrieving Sensor Information
42
Displaying FRU Information
44
Displaying System Event Logs
45
Using Remote Console
46
Displaying All Remote Server Sensors
47
Adjusting the Monitoring Settings
48
Controlling the Remote Server Power
50
Viewing PET Information
51
ASUS Host Management Controller Setup
54
Installing and Launching the ASUS Host Management Controller Setup Utility
54
Command Fields
55
Initial
55
View
55
Set
58
Monitor
59
Help
60
Chapter 4: Web-Based User Interface
61
Web-Based User Interface
61
Loging in the Utility
62
Using the Utility
63
System Information
64
Server Health
64
Sensor Readings (with Thresholds)
65
Event Log
65
Configuration
66
Alerts
66
Pef
67
Mouse Mode
67
Network
68
Smtp
68
Ssl
69
Users
69
Configure LDAP
70
Date/Time/Ntp Settings
70
Remote Control
71
Console Redirection
71
Server Power Control
72
Capture Screen Video
72
Chassis Identify Command
73
Maintenance
73
Languages
74
Appendix: Reference Information
76
BMC Connector
76
A.1 BMC Connector
76
LAN Ports for Server Management
77
Troubleshooting
78
A.3 Troubleshooting
78
BMC Sensor Codes Table
79
4
Based on 1 rating
Ask a question
Give review
