ASUS B85M-D PLUS
2‑17
CPU Internal Power Saving Control
Power Saving Level 1 Threshhold [Auto]
Allows you to set the power saving level 1 threshhold.
Use the <+> and <‑> keys to adjust the value.
Power Saving Level 2 Threshhold [Auto]
Allows you to set the power saving level 2 threshhold.
Use the <+> and <‑> keys to adjust the value.
Power Saving Level 3 Threshhold [Auto]
Allows you to set the power saving level 3 threshhold.
Use the <+> and <‑> keys to adjust the value.
2.5.12 CPU Core Voltage [Auto]
This item allows you to set the CPU core voltage. Increase the voltage when increasing the
core frequency. Conguration options: [Auto] [Manual Mode] [Offset Mode]
CPU Core Voltage Override [Auto]
This item appears only when you set the CPU Core Voltage to [Manual Mode] and allows you
to set the CPU core voltage override. The values range from 0.001V to 1.920V with a 0.001V
interval.
Offset Mode Sign [+]
This item appears only when you set the CPU Core Voltage to [Offset Mode] and allows you
to set the offset mode sign. Conguration options: [+] [‑]
CPU Core Voltage Offset [Auto]
This item appears only when you set the CPU Core Voltage to [Offset Mode] and
allows you to set the CPU core voltage offset. The values range from 0.001V to 0.999V
with a 0.001V interval.
2.5.13 CPU Cache Voltage [Auto]
This item allows you to set the CPU Cache voltage. Increase the cache voltage when
increasing the ring frequency. Conguration options: [Auto] [Manual Mode] [Offset Mode]
[Adaptive Mode].
[Adaptive Mode] is available for some specic CPU types.
CPU Cache Voltage Override [Auto]
This item appears only when you set the CPU Cache Voltage to [Manual Mode] and allows
you to set the CPU Cache voltage override. The values range from 0.001V to 1.920V with a
0.001V interval.
Offset Mode Sign [+]
This item appears only when you set the CPU Cache Voltage to [Offset Mode] or [Adaptive
Mode] and allows you to set the offset mode sign. Conguration options: [+] [‑]
