Asus B85M-E R2.0 User Manual

ASUS B85M-E R2.0
1-3
1.2.3 Motherboard layout
B85M-E R2.0
PCIEX16_1
PCIEX16_2
PCIEX1_1
PCI1
F_PANEL
SPEAKERCHASSIS
CLRTC
USB1112
USB1314
AAFP
EATXPWR
CPU_FAN
CHA_FAN1
CHA_FAN2
BATTERY
Super
I/O
ALC
887
ASM
1083
RTL
8111F
ASM
1442K
128Mb
BIOS
TPM
24.4cm(9.6in)
Intel
®
B85
DDR3 DIMM_A1 (64bit, 240-pin module)
LGA1150
DDR3 DIMM_A2 (64bit, 240-pin module) DDR3 DIMM_B1 (64bit, 240-pin module) DDR3 DIMM_B2 (64bit, 240-pin module)
SATA3G_1 SATA3G_2
SATA6G_3 SATA6G_4
SATA6G_1 SATA6G_2
AUDIO
KBMS
HDMI_DP
USB34
22.6cm(8.9in)
DVI
VGA
USB910
LAN_USB3_56
DIGI
+VRM
USB3_12
COM
LPT
EATX12V
1321 4 1
7
7
6
2
5
11 10 9 81213141516

Asus B85M-E R2.0 Specifications

General

Form Factor	Micro ATX
Chipset	Intel B85
CPU Socket	LGA 1150
Memory Slots	4
Memory Type	DDR3
Maximum Memory	32 GB
PCIe x16 Slots	1
PCIe x1 Slots	2
SATA 6Gb/s	4
SATA 3Gb/s	2
Audio	Realtek ALC887 8-Channel High Definition Audio CODEC
RAID Support	RAID 0, 1, 5, 10
USB 3.0 Ports	4 (2 rear, 2 via header)
USB 2.0 Ports	8 (4 at back panel, 4 via internal header)
LAN	Realtek 8111G, 1 x Gigabit LAN Controller
Memory Standard	DDR3 1600/1333/1066 MHz
