2-14
Chapter 2: Getting started
Target Cache Speed : xxxxMHz
DisplaysthetargetCachespeed.
Target DMI/PEG Clock : xxxxMHz
DisplaysthetargetDMI/PEGclock.
Target iGPU Speed : xxxxMHz
DisplaysthetargetiGPUspeed.
2.5.1 CPU Core Ratio [Auto]
AllowsyoutosettheCPUcoreratioautomaticallyormanually.
[Auto] SetsallCPUCoreRatiotoIntel
®
CPUdefaultsettingsautomatically.
[SyncAllCores] AllowsyoutosetCPUCoreRatiosettingsforallcores.
[PerCore] AllowsyoutosetCPUCoreRatioindividually.
ThefollowingtwoitemsappearonlywhenyousettheCPU Core Ratio to [Sync All
Cores] or [Per Core].
1-Core Ratio Limit [Auto]
Select[Auto]toapplytheCPUdefaultTurboRatiosettingormanuallyassigna1-Core
Limitvalue,whichshouldbehigherthanorequaltothe2-CoreRatioLimit.
2-/3-/4-Core Ratio Limit [Auto]
TheseitemsbecomecongurableonlywhenyousettheCPU Core Ratioitemto[Per
Core].
2.5.2 Min CPU Cache Ratio [Auto]
Allowsyoutosettheuncoreratiooftheprocessortoitspossibleminimumvalue.
Congurationoptions:[Auto][8]~[33].
2.5.3 Max CPU Cache Ratio [Auto]
Allowsyoutosettheuncoreratiooftheprocessortoitspossiblemaximumvalue.
Congurationoptions:[Auto][8]~[33].
2.5.4 BCLK Frequency : DRAM Frequency Ratio [Auto]
AllowsyoutosettheCPUbusspeedtoDRAMfrequencyratio.
[Auto] DRAMspeedissettotheoptimizedsettings.
[100:133] TheBCLKfrequencytoDRAMspeedratioissetto100:133.
[100:100] TheBCLKfrequencytoDRAMspeedratioissetto100:100.
