Asus B85M-G PLUS - DRAM Frequency and Graphics Ratio Settings; DRAM Timing Control; DIGI+ VRM Settings

ASUS B85M-G PLUS
2-15
2.5.5 DRAM Frequency [Auto]
Allowsyoutosetthememoryoperatingfrequency.Thecongurableoptionsvarywiththe
BCLK(baseclock)frequencysetting.Selecttheautomodetoapplytheoptimizedsetting.
Congurationoptions:[DDR3-800MHz][DDR3-1066MHz][DDR3-1333MHz][DDR3-
1400MHz][DDR3-1600MHz]
Selectingaveryhighmemoryfrequencymaycausethesystemtobecomeunstable!Ifthis
happens,reverttothedefaultsetting.
2.5.6 Max. CPU Graphics Ratio [Auto]
[Auto] TheCPUGraphicsratioissettoitsoptimizedsettingdependingonthe
systemloading.
[Manaul] Usethe<+>or<->keystoadjusttheoptimalCPUGraphicsratio.The
valuemayvarydependingonthesystemloading.
2.5.7 GPU Boost [As is]
AllowsyoutoenabletheGPUBoosttoacceleratetheintegratedGPUforextremegraphics
performance.Congurationoptions:[Asis][Enabled].
2.5.8 EPU Power Saving Mode [Disabled]
AllowsyoutoenableordisabletheEPUpowersavingfunction.Congurationoptions:
[Disabled][Enabled]
2.5.9 DRAM Timing Control
ThesubitemsinthismenuallowyoutosettheDRAMtimingcontrolfeatures.Usethe
<+>and<->keystoadjustthevalue.Torestorethedefaultsetting,type[auto]usingthe
keyboardandpressthe<Enter>key.
Changingthevaluesinthismenumaycausethesystemtobecomeunstable!Ifthis
happens,reverttothedefaultsettings.
2.5.10 DIGI+ VRM
CPU Load-Line Calibration [Auto]
Load-lineisdenedbyIntelVRMspecicationandaffectsCPUvoltage.TheCPUworking
voltagewilldecreaseproportionallytoCPUloading.Highervaluegetsahighervoltageand
betteroverclockingperformance,butincreasestheCPUandVRMthermalconditions.This
itemallowsyoutoadjustthevoltagerangefromthefollowingpercentagestoboostthe
systemperformance:0%(Regular),25%(Medium),50%(High),75%(UltraHigh),and100%
(Extreme).Congurationoptions:[Auto][Regular][Medium][High][UltraHigh][Extreme]
TheactualperformanceboostmayvarydependingonyourCPUspecication.
