Asus BE24C Series User Manual

2-2 Chapter 2: Setup
BE229/BE239/BE249 simple base
1. Have the front of the monitor face down on a table.
2. Remove the rubbers in the four screw holes. (Figure 1)
3. Remove the base (Figure 2).
4. Use a screwdriver to remove the screw on the hinge (Figure 3), then remove
the hinge.
1
2
(Figure 1) (Figure 2)
1
2
(Figure 3)
BE209/BE229/BE239/BE249/BE24A/BE24W/BE27A
height adjustment base
1. Have the front of the monitor face down on a table.
2. Press the release button, and then detach the arm/base from the monitor (Figure
2).
2
1
(Figure 1) (Figure 2)
