Asus BE24EQK - Connecting Monitor Cables

2-5ASUS BE Series LCD Monitor
• Slide the webcam cover shutter on the top to open or close the lens.
Remove the protection lm on the front of the webcam before using.
2.6 Connecting the cables
Connect the cables as the following instructions:
BE24EQK BE24EQSK
 : Connect one end of the power cord securely to
the monitor’s AC input port, the other end to a power outlet.
 :
a. Plug one end of the VGA/DisplayPort/HDMI cable to the monitor’s VGA/
DisplayPort/HDMI jack.
b. Connect the other end of the VGA/DisplayPort/HDMI cable to your
computer's VGA/DisplayPort/HDMI jack.
c. Tighten the two screws to secure the VGA connector.
 connect one end of the audio cable to the
monitor’s Audio-in port, the other end to the computer’s audio-out port.
  connect the end with plug type to the monitor’s
earphone jack when an HDMI/DisplayPort signal is fed.
