4-20 Chapter 4: BIOS setup
CPU Voltage [Auto]
Allows you to select the CPU voltage. The text color in the conguration eld
corresponds to the onboard CPU LED color, both of which indicate CPU voltage
condition. Refer to page 2-1 for CPU LED denition.
Conguration options: [Auto] [1.10000V] [1.10625V] [1.11250V] [1.11875V]
[1.12500V] [1.13125V] [1.13750V] [1.14375V] [1.50000V] [1.15625V] [1.16250V]
[1.16875V] [1.17500V] [1.18125V] [1.18750V] [1.19375V] [1.20000V] [1.20625V]
[1.21250V] [1.21875V] [1.22500V] [1.23125V] [1.23750V] [1.24375V] [1.25000V]
[1.25625V] [1.26250V] [1.26875V] [1.27500V] [1.28125V] [1.28750V] [1.29375V]
[1.30000V]~[1.80000V] [1.80625V] [1.81250V] [1.81875V] [1.82500V] [1.83125V]
[1.83750V] [1.84375V] [1.85000V] [1.85625V] [1.86250V] [1.86875V] [1.87500V]
[1.88125V] [1.88750V] [1.89375V] [1.90000V]
Refer to the CPU documentation before setting the CPU voltage. Setting a
high voltage may damage the CPU permanently, and setting a low voltage may
make the system unstable.
CPU Voltage Reference [Auto]
Conguration options: [Auto] [0.531V] [0.545V] [0.561V] [0.576V] [0.581V] [0.597V]
[0.618V] [0.635V]
Loadline Calibration [Auto]
Conguration options: [Auto] [Disabled] [Enabled]
FSB Termination Voltage [Auto]
Allows you to select the front side bus (FSB) termination voltage. The text color
in the conguration eld indicates FSB termination voltage condition. When you
set the NB LED Selection item to [FSBT Volt], the onboard northbridge LED
displays FSB termination voltage condition. Refer to page 2-2 for northbridge LED
denition.
Conguration options: [Auto] [1.20V] [1.22V] [1.24V] [1.26V] [1.28V] [1.30V]~
[1.70V] [1.72V] [1.74V] [1.76V] [1.78V] [1.80V]
Setting a high FSB termination voltage may damage the chipset and CPU.
North Bridge Voltage [Auto]
Allows you to select the northbridge voltage. The text color in the conguration eld
indicates northbridge voltage condition. When you set the NB LED Selection item
to [NB Volt], the onboard northbridge LED displays northbridge voltage condition.
Refer to page 2-2 for northbridge LED denition.
Conguration options: [Auto] [1.25V] [1.27V] [1.29V] [1.31V]~[1.97V] [1.99V]
[2.01V] [2.03V]
North Bridge Voltage Refernece [Auto]
Conguration options: [Auto] [0.61x] [0.67x]
