Rear panel
1. USB 3.0 ports.USB 3.0 ports. These Universal Serial Bus 3.0 (USB 3.0) ports connect to USB 3.0
devices such as a mouse, printer, scanner, camera, PDA, and others.
2. USB 2.0 ports.USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports connect to USB 2.0
devices such as a mouse, printer, scanner, camera, PDA, and others.
3. Microphone port (pink).Microphone port (pink). This port connects to a microphone.
4. Headphone port (lime).Headphone port (lime). This port connects to a headphone or speaker.
5. Power button.Power button. Press this button to turn on your computer.
6. Optical disk drive eject button.Optical disk drive eject button. Press this button to eject the optical disk drive tray.
7. Optical disk drive bay (empty).Optical disk drive bay (empty). Allows you to install an additional optical disk drive in
this bay.
8. Optical disk drive bay.Optical disk drive bay. There is an optical disk drive in this bay.
9. Memory Stick™ / Memory Stick Pro™ card slot.Memory Stick™ / Memory Stick Pro™ card slot. Insert a Memory Stick™ / Memory
Stick Pro™ card into this slot.
10. Secure Digital™ / MultiMediaCard slot.Secure Digital™ / MultiMediaCard slot. Insert a Secure Digital™ / MultiMediaCard
card into this slot.
11. CompactFlashCompactFlash
®
/ Microdrive™ card slot. Insert a CompactFlash
®
/ Microdrive™ card
into this slot.
