Asus DSL-AC55U Quick Start Guide

52
Italiano
Installazione
1. Inserite l'estremità dell'adattatore
AC nella porta di ingresso dell'al-
imentazione e collegate l'altra
estremità ad una presa di corrente.
2. Collegate un'estremità del cavo
RJ-11 alla porta DSL del vostro mo-
dem router e l'altra estremità alla
porta DSL del vostro ltro splitter.
3. Usando un cavo di rete collegate il
vostro computer ad una porta LAN
del modem router xDSL.
Accensione
1. Accendete il vostro model xDSL e aspettate qualche minuto in modo che la connessione ad
Internet venga stabilita correttamente.
2. Quando il LED DSL smette di lampeggiare e rimane sso potete avviare il processo di congu-
razione tramite l'installazione guidata (QIS).
NOTA: Per maggiori dettagli sulla QIS potete fare riferimento al manuale utente.
Per iniziare
1. Avviate il vostro browser e inserite il nome utente (admin) e la password (admin).
DSL E-WAN
WPS
Wi-Fi on/off
Wall power outlet
Wall telephone outlet
Computer
Splitter
Phone
DSL
LAN
Power
U11624_DSL-AC55U_QSG_125x168mm.indb 52 2016/8/29 16:38:30

Asus DSL-AC55U Specifications

General

Ethernet WAN	Yes
SIM card slot	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
Number of WLAN connections (max)	1
WLAN data transfer rate (first band)	300 Mbit/s
Product type	Tabletop router
Product color	Black
VPN support	IPSec Pass-Through PPTP Pass-Through L2TP Pass-Through PPTP server OpenVPN server PPTP client L2TP client OpenVPN client
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	4
Output current	1.5 A
Output voltage	12 V
AC input voltage	110 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	18 W
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Certification	CE, Telepermit, RCM
Mac operating systems supported	Mac OS X 10.1 Puma, Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	149 mm
Width	207 mm
Height	36 mm
Weight	360 g
