Asus DSL-AC68U User Manual

5
1 Getting to know your wireless
router
Package contents
• If any of the items is damaged or missing, contact ASUS for
technical inquiries and support. Refer to the ASUS Support
Hotline list at the back of this user manual.
• Keep the original packaging material in case you would need
future warranty services such as repair or replacement.
ADSL/VDSL WiFi modem router
Network cable
AC adapter
Phone cable
Quick Start Guide
Warranty card
Support CD (User Manual/utilities)
Splitter (varies with regions)

Asus DSL-AC68U Specifications

General

VPN support	IPSec, PPTP, L2TP, PPTP server, OpenVPN server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1300 Mbit/s
USB version	3.2 Gen 1 (3.1 Gen 1)
Rack mounting	-
Frequency range	2.4 - 5 GHz
Bandwidth (first)	2.4 GHz
Bandwidth (second)	5 GHz
USB ports quantity	1
WLAN data transfer rates supported	600, 1300 Mbit/s
Ethernet LAN (RJ-45) ports	4
Antennas quantity	3
Antenna gain level (max)	3 dBi
Security algorithms	256-bit WEP, 64-bit WEP, WPA-PSK, WPA2-PSK, WPS
Product color	Black
Flash memory	128 MB
Internal memory	256 MB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	83.3 mm
Width	220 mm
Height	160 mm
Weight	640 g
